HP+ Wall Assembly – XR Series

The HP+^™ Wall System XR Series is a strong structural assembly that complies with codes when built as an air barrier system (ABS). Nominal insulation R-values can range from of R-25.2 up to R-45.8 with 2x4 wood framing. The XR Series offers exceptional energy and cost efficiencies.

Key Benefits:

Build Stronger: Create a stronger wall assembly and use less wood than traditional construction.
Build Smarter: Construct a wall assembly that incorporates continuous insulation and an air/vapour barrier system without the need for a conventional vapour and weather resistive barrier.
Build Sustainable: Minimize energy loss with reduced air leakage and high R-values while enhancing indoor comfort.

Systematic Success

The HP+^™ Wall System XR Series is designed to deliver a smart new way to build affordable, high performance homes.
The wall assembly features the following:

2x6 bottom and top plates
2x4 wood framing at 16"or 24" on center construction
2" Neopor^® graphite-enhanced rigid thermal foam insulation. Also available in different thicknesses and R-values to fit your climate zone needs and code requirements
Polyurethane sealant
2 1/2" WALLTITE^® insulating air/vapour barrier material
2" x 4" finished timber girts with 1/2" plywood strips
Extra room to add more WALLTITE^® for an increased R-value

Strength in Numbers

By combining 2x4 framing with foam sheathing and spray polyurethane foam in a composite design, the HP+ Wall System XR Series can increase structural strength while reducing lumber content and eliminating the need for plywood or OSB sheathing. When properly designed and installed, the HP+ Wall System can offer one of the best values available for residential construction.
Benefits include:

Can reduce lumber content by eliminating wood sheathing (plywood, OSB)
Wood girts allow WALLTITE^® to get behind studs greatly reducing thermal bridging and increasing effective R-value
Stronger walls with increased lateral resistance compared to a typical wall (studs and exterior sheathing)
Improved moisture management that can mitigate thermal and structural issues
Mitigate thermal and structural issues; reducing potential builder callbacks

Build a Better Barrier - Thermal, Air, Water and Vapour Drive

With integrated thermal, air, water and vapour flow management in a single system, the HP+ Wall System XR Series provides an effective building envelope against severe Canadian climates.

Provides higher thermal performance in 2x4 wood framing and interior square footage without increasing the building's footprint
Reduces thermal bridging through continuous insulation which can also perform as a weather resistive barrier
Creates a superior air and vapour barrier using WALLTITE^® and Polyurethane sealant
